TYT TH-UV8800 Dual Band FM Transceiver with Cross Band Repeating Support
Brand:
TYT
TYT TH-UV8800 Dual Band FM Transceiver with Cross Band Repeating Support
TYT TH-UV8800 Dual Band FM Transceiver with Cross Band Repeating Support
TYT TH-UV8800 Dual Band FM Transceiver with Cross Band Repeating Support
The TYT TH-UV8800 is a high-performance dual-band VHF/UHF mobile transceiver designed for amateur radio operators requiring flexible communication capabilities and reliable mobile operation. Featuring simultaneous dual-band monitoring, cross-band repeat functionality, high-power output, extensive memory storage, and a detachable control panel, the TH-UV8800 is ideal for mobile installations, repeater access, emergency communications, and base station use.
Key Features
- Dual-band VHF and UHF FM mobile transceiver
- Simultaneous dual receive operation with independent band monitoring
- Cross-band repeat functionality for extended communication coverage
- 50 Watt RF output on VHF bands
- 40 Watt RF output on UHF bands
- Selectable high, medium, and low power settings
- 809 programmable memory channels
- Alphanumeric memory channel naming capability
- Large dual-frequency LCD display with adjustable illumination
- Detachable front control panel for flexible vehicle installation
- Dual VFO operation with independent tuning control
- Built-in CTCSS encoder and decoder
- Built-in DCS encoder and decoder
- DTMF encode and decode functionality
- 2-Tone and 5-Tone signaling support
- Tone scan and repeater access functions
- Automatic repeater shift support
- Wide and narrow FM operation modes
- Priority channel monitoring capability
- Programmable scan and memory management functions
- Emergency alarm feature
- Busy channel lockout protection
- Time-out timer functionality
- Compander function for enhanced audio quality
- Programmable side and front-panel function keys
- Built-in cooling fan for stable high-power operation
- PC programming and firmware configuration support
- Radio cloning capability for simplified setup
- External speaker connectivity support
- Suitable for repeater operation, emergency communications, public service activities, and mobile amateur radio applications
Typical Uses
- Dual-band VHF/UHF repeater operation
- Cross-band repeater applications
- Mobile amateur radio installations
- Emergency and disaster communications
- Public service and event support communications
- Fixed-station VHF/UHF operation
- General amateur radio communications
In the Box
- TYT TH-UV8800 Dual-Band Transceiver
- DTMF Hand Microphone
- Detachable Control Panel
- Control Head Separation Cable
- DC Power Cable
- Mobile Mounting Bracket
- Microphone Hanger
- Mounting Hardware Kit
- User Documentation
| Brand | TYT |
| Model Number | TH-UV8800 |
| Product Type | Dual-Band VHF/UHF FM Mobile Transceiver |
| Frequency Coverage TX VHF | 136-174 MHz |
| Frequency Coverage TX UHF | 400-480 MHz |
| Frequency Coverage RX VHF | 136-174 MHz |
| Frequency Coverage RX UHF | 400-480 MHz |
| Operating Modes | FM/NFM |
| RF Output Power VHF | 50W/25W/10W |
| RF Output Power UHF | 40W/20W/10W |
| Dual Receive | Simultaneous Dual Receive |
| Cross-Band Repeat | Supported |
| Memory Channels | 809 |
| Channel Naming | Supported |
| Display | Dual-Frequency Backlit LCD |
| Control Head | Detachable |
| Dual VFO | Supported |
| CTCSS Encoder | Built-In |
| CTCSS Decoder | Built-In |
| DCS Encoder | Built-In |
| DCS Decoder | Built-In |
| DTMF Encode | Supported |
| DTMF Decode | Supported |
| 2-Tone Signaling | Supported |
| 5-Tone Signaling | Supported |
| Tone Scan | Supported |
| Automatic Repeater Shift | Supported |
| Priority Channel | Supported |
| Emergency Alarm | Supported |
| Busy Channel Lockout | Supported |
| Time Out Timer | Supported |
| Compander | Supported |
| Wide/Narrow FM | Supported |
| Programming | PC Programmable |
| Cloning Function | Supported |
| External Speaker Jack | Supported |
| Cooling System | Built-In Cooling Fan |
| Frequency Stability | ±2.5ppm |
| Channel Spacing | 12.5kHz/25kHz |
| Antenna Connector | SO-239 |
| Antenna Impedance | 50 Ohm |
| Power Supply | 13.8VDC ±15% |
| Current Consumption RX | Less Than 0.8A |
| Current Consumption TX | Up To 11A |
| Dimensions | 140 x 43 x 168 mm |
| Weight | Approx. 1.2kg |
| Microphone | DTMF Hand Microphone Included |
