NanoVNA-H Vector Network Analyzer
Brand:
NanoVNA
NanoVNA-H Vector Network Analyzer
NanoVNA-H Vector Network Analyzer
NanoVNA-H Vector Network Analyzer
The NanoVNA-H is a compact handheld Vector Network Analyzer (VNA) designed for RF measurements, antenna tuning, filter evaluation, cable testing, and impedance analysis. Covering frequencies from 50 kHz to 1.5 GHz with dual-port S-parameter measurements, it provides professional RF analysis capabilities in a portable instrument suitable for amateur radio, RF laboratories, education, and field service applications.
Key Features
- Portable handheld Vector Network Analyzer (VNA)
- Frequency coverage from 50 kHz to 1.5 GHz
- Dual-port S11 and S21 measurement capability
- Measures SWR, return loss, impedance, phase and insertion loss
- Supports Smith Chart, Polar, LogMag, Phase and Delay displays
- 4-inch IPS color touchscreen display
- High-resolution 480 × 320 display
- Up to 401 measurement points per sweep
- Fast sweep performance with real-time display updates
- Built-in calibration memory
- Full SOLT (Short, Open, Load, Through) calibration support
- Multiple trace display capability
- Marker functions for precise frequency measurements
- Internal rechargeable lithium battery
- USB Type-C interface for charging and PC connectivity
- Compatible with NanoVNA Saver software
- Touchscreen and rotary encoder operation
- Stores calibration and measurement data internally
- Supports Touchstone (S1P/S2P) file export
- 50 Ohm measurement system
- SMA female RF connectors
- Compact aluminum alloy enclosure
- Ideal for antenna tuning and matching
- Suitable for filter, cable and amplifier measurements
- Excellent portable RF measurement solution for amateur radio and laboratory applications
Typical Uses
- Antenna tuning and matching
- Coaxial cable testing
- RF filter characterization
- Amplifier gain measurements
- Impedance analysis
- Smith Chart analysis
- Amateur radio and RF laboratory measurements
In the Box
- NanoVNA-H Vector Network Analyzer
- SOLT calibration kit (Open, Short, Load, Through)
- 2 × SMA RF test cables
- USB Type-C charging/data cable
- Stylus
- User manual
| Brand | NanoVNA |
| Model Number | NanoVNA-H |
| Product Type | Vector Network Analyzer |
| Frequency Range | 50kHz-1.5GHz |
| Measurement Ports | 2 |
| Measurement Parameters | S11/S21 |
| Display | 4.0-inch IPS LCD |
| Display Resolution | 480x320 |
| Measurement Points | Up To 401 |
| Dynamic Range | 70dB |
| Output Power | -13dBm |
| Frequency Accuracy | 0.5ppm |
| Impedance | 50 Ohm |
| Connector Type | SMA Female |
| Calibration | SOLT |
| Calibration Storage | Supported |
| Touchstone Export | S1P/S2P |
| USB Interface | USB Type-C |
| PC Software | NanoVNA Saver |
| Battery | 5000mAh Rechargeable Lithium |
| Battery Runtime | Up To 8 Hours |
| Enclosure | Aluminum Alloy |
| Application | Antenna Analysis |
| Application | Filter Testing |
| Application | Cable Testing |
| Application | RF Measurement |
Warranty:
12 Months of Warranty against Manufacturing Defects Only
