ICOM ID-52A VHF/UHF Multi Function D-Star Handheld Transceiver
Brand:
ICOM
ICOM ID-52A VHF/UHF Multi Function D-Star Handheld Transceiver
ICOM ID-52A VHF/UHF Multi Function D-Star Handheld Transceiver
ICOM ID-52A VHF/UHF Multi Function D-STAR Handheld Transceiver
The ICOM ID-52A is a premium dual-band VHF/UHF handheld transceiver featuring D-STAR digital voice and data communication, integrated Bluetooth®, GPS functionality, and simultaneous dual-band monitoring. Combining advanced digital networking capabilities with a large color display, waterfall spectrum scope, and rugged portable construction, the ID-52A is designed for amateur radio operators seeking high-performance portable communications.
Key Features
- Dual-band VHF/UHF amateur radio handheld transceiver
- D-STAR digital voice and low-speed data communication capability
- Conventional FM and D-STAR DV operating modes
- Simultaneous dual-watch operation for monitoring two frequencies
- Large 2.3-inch full-color TFT display
- Integrated Bluetooth® connectivity for wireless accessories and smartphone integration
- Built-in GPS receiver for location services and D-STAR functions
- Terminal Mode and Access Point Mode support
- DR (D-STAR Repeater) mode for simplified repeater access
- Band Scope and Waterfall Display for visual signal monitoring
- Automatic nearby repeater search using GPS data
- Wideband receive capability including VHF aviation band reception
- FM broadcast reception support
- D-PRS position reporting functionality
- Voice recording and playback capability
- Picture Share functionality with compatible software
- Integrated microSD card slot for memory backup and data storage
- USB connectivity for programming and firmware updates
- High-quality 750 mW audio output for clear communications
- Compatible with RS-MS1A Android smartphone control applications
- Wireless operation with optional Bluetooth accessories
- IPX7 waterproof construction for outdoor operation
- Compact rugged handheld design for portable use
- High-capacity lithium-ion battery system
- Extensive memory and repeater database management capability
- Ideal for D-STAR networking, repeater operation, travel, emergency communications, and portable amateur radio activities
Typical Uses
- D-STAR digital voice and data communications
- Portable VHF/UHF amateur radio operation
- Worldwide communication through D-STAR networks
- Emergency and disaster communications
- Travel and field deployments
- Airband and broadcast monitoring
- Repeater and hotspot communications
In the Box
- ICOM ID-52A Handheld Transceiver
- BP-272 Lithium-Ion Battery Pack
- Flexible Antenna
- BC-202IP3 AC Adapter
- USB Cable
- Belt Clip
- Hand Strap
- User Documentation
| Brand | ICOM |
| Model Number | ID-52A |
| Product Type | VHF/UHF D-STAR Handheld Transceiver |
| Frequency Coverage TX VHF | 144-148 MHz |
| Frequency Coverage TX UHF | 430-450 MHz |
| Frequency Coverage RX VHF | 108-174 MHz |
| Frequency Coverage RX UHF | 375-550 MHz |
| Airband Receive | 108-136.99166 MHz AM |
| FM Broadcast Receive | 76-108 MHz |
| Operating Modes | FM/FM-N/DV(D-STAR) |
| RF Output Power | 5W/2.5W/1W/0.5W |
| Digital Voice System | D-STAR |
| Dual Watch | Supported |
| GPS Receiver | Built-In |
| Bluetooth | Built-In |
| Terminal Mode | Supported |
| Access Point Mode | Supported |
| DR Mode | Supported |
| Band Scope | Built-In |
| Waterfall Display | Built-In |
| D-PRS | Supported |
| Voice Recording | Supported |
| Picture Share | Supported |
| Display | 2.3in Color TFT LCD |
| Memory Storage | microSD Card |
| USB Interface | Supported |
| Speaker Output | 750mW |
| Waterproof Rating | IPX7 |
| Battery Pack | BP-272 Li-Ion |
| Battery Capacity | 1880mAh |
| Antenna Connector | SMA Female |
| Frequency Stability | ±2.5ppm |
| Dimensions | 61 x 111 x 31 mm |
| Weight | Approx. 295g |
| Bluetooth Audio | Supported |
| Smartphone Control | RS-MS1A Compatible |
